RX8130CE時鐘模塊以高精度低功耗引領新時代
  • 文章出處：http://m.shangyingkeji.cn/
  • 責任編輯：加科電子
  • 人氣：1924
  • 發表時間：2024-11-26

隨著科技的飛速發展,電子設備的智能化和集成化程度越來越高,對時間精度和穩定性的要求也越來越高,EPSON愛普生進口晶振旗下的RX8130CE（X1B000311000100）實時時鐘模塊的出現,為解決這些挑戰提供了一種高效且可靠的方案,愛普生晶振公司這款實時時鐘模塊憑借其高精度,低功耗以及豐富的功能,迅速在電子設備行業崛起,RX8130CE實時時鐘模塊集成了32.768kHz的晶振單元,并配備了I2C總線接口,使其能夠獨立完成計時和事件記錄的功能,該模塊不僅具備傳統的年,月,日,周,時,分,秒計時功能,還新增了時間報警器,間隔計時器和時間更新中斷等實用功能,這些功能都集成在3.2x2.5x1.0mm的微型陶瓷封裝內,使得RX8130CE能夠輕松適應各種小型電子設備的需求。

型號料號尺寸電源電壓工作溫度頻率容差頻率容差溫度時間偏差
RA8900CEX1B000271A004003.20x2.50x1.002.5 to 5.5-40 to +85+/- 3.4-40 to +85+/- 9
RA8900CEX1B000271A005003.20x2.50x1.002.5 to 5.5-40 to +85+/- 5-40 to +85+/- 13
RA8900CEX1B000271A006003.20x2.50x1.002.5 to 5.5-40 to +85+/- 5-30 to +70+/- 13
RX8900CEX1B0003010001003.20x2.50x1.002.5 to 5.5-40 to +85+/- 3.4-40 to +85+/- 9
RX8900CEX1B0003010002003.20x2.50x1.002.5 to 5.5-40 to +85+/- 5-40 to +85+/- 13
RX8900CEX1B0003010003003.20x2.50x1.002.5 to 5.5-40 to +85+/- 5-30 to +70+/- 13
RX8130CEX1B0003110001003.20x2.50x1.001.25 to 5.5-40 to +85+5 +/- 23@+25+/- 60
RX8804CEX1B0003710001003.20x2.50x1.001.6 to 5.5-40 to +105+/- 3.4-40 to +85+/- 9
RX8804CEX1B0003710002003.20x2.50x1.001.6 to 5.5-40 to +105+/- 5-40 to +85+/- 13
RA8804CEX1B000381A001003.20x2.50x1.001.6 to 5.5-40 to +105+/- 3.4-40 to +85+/- 9
RA8804CEX1B000381A002003.20x2.50x1.001.6 to 5.5-40 to +105+/- 5-40 to +85+/- 13
RX8111CEX1B0004210001003.20x2.50x1.001.6 to 5.5-40 to +105+/- 11.5@+25+/- 30
RX8111CEX1B0004210002003.20x2.50x1.001.6 to 5.5-40 to +105+/- 23@+25+/- 60
RX4111CEX1B0004310001003.20x2.50x1.001.6 to 5.5-40 to +105+/- 11.5@+25+/- 30
RX4111CEX1B0004310002003.20x2.50x1.001.6 to 5.5-40 to +105+/- 23@+25+/- 60
RX4901CEX1B0004710001003.20x2.50x1.001.6 to 5.5-40 to +105+/- 3-40 to +85+/- 8
RX4901CEX1B0004710002003.20x2.50x1.001.6 to 5.5-40 to +105+/- 5-40 to +85+/- 13
RX4901CEX1B0004710003003.20x2.50x1.001.6 to 5.5-40 to +105+/- 3-40 to +85+/- 8
RX4901CEX1B0004710004003.20x2.50x1.001.6 to 5.5-40 to +105+/- 5-40 to +85+/- 13
RX4901CEX1B0004710005003.20x2.50x1.001.6 to 5.5-40 to +105+/- 3-40 to +85+/- 8
RX4901CEX1B0004710006003.20x2.50x1.001.6 to 5.5-40 to +105+/- 5-40 to +85+/- 13
RX4901CEX1B0004710007003.20x2.50x1.001.6 to 5.5-40 to +105+/- 3-40 to +85+/- 8
RX4901CEX1B0004710008003.20x2.50x1.001.6 to 5.5-40 to +105+/- 5-40 to +85+/- 13
RX8901CEX1B0004810001003.20x2.50x1.001.6 to 5.5-40 to +105+/- 3-40 to +85+/- 8
RX8901CEX1B0004810002003.20x2.50x1.001.6 to 5.5-40 to +105+/- 5-40 to +85+/- 13
RX8901CEX1B0004810003003.20x2.50x1.001.6 to 5.5-40 to +105+/- 3-40 to +85+/- 8
RX8901CEX1B0004810004003.20x2.50x1.001.6 to 5.5-40 to +105+/- 5-40 to +85+/- 13
RA4000CEX1B000491A001003.20x2.50x1.001.6 to 5.5-40 to +125+/- 5-40 to +85+/- 13
RA4000CEX1B000491A009003.20x2.50x1.001.6 to 5.5-40 to +125+/- 5-40 to +85+/- 13
RA4000CEX1B000491A010003.20x2.50x1.001.6 to 5.5-40 to +125+/- 5-40 to +85+/- 13
RA4000CEX1B000491A011003.20x2.50x1.001.6 to 5.5-40 to +125+/- 5-40 to +85+/- 13
RA4000CEX1B000491A019003.20x2.50x1.001.6 to 5.5-40 to +125+/- 5-40 to +85+/- 13
RA8000CEX1B000501A001003.20x2.50x1.001.6 to 5.5-40 to +125+/- 5-40 to +85+/- 13
RA8000CEX1B000501A009003.20x2.50x1.001.6 to 5.5-40 to +125+/- 5-40 to +85+/- 13
RX-4045SAQ4140455100020010.10x7.40x3.301.7 to 5.5-40 to +85+/- 5@+25+/- 13
RX-4045SAQ4140455200010010.10x7.40x3.301.7 to 5.5-40 to +85+5 +/- 5@+25+/- 13
RX-4571SAQ4145715200010010.10x7.40x3.301.6 to 5.5-40 to +85+5 +/- 23@+25+/- 60
RX-4571LCQ414571C20002003.60x2.80x1.201.6 to 5.5-40 to +85+5 +/- 23@+25+/- 60
RX-8025SAQ4180255100020010.10x7.40x3.301.7 to 5.5-40 to +85+/- 5@+25+/- 13
RX-8571SAX1B00007200010010.10x7.40x3.301.6 to 5.5-40 to +85+5 +/- 23@+25+/- 60
RX-4803SAX1B00013100010010.10x7.40x3.301.6 to 5.5-40 to +85+/- 5-40 to +85+/- 13
RX-8803LCX1B0001420002003.60x2.80x1.201.6 to 5.5-40 to +85+/- 5-40 to +85+/- 13
RX-8803LCX1B0001420003003.60x2.80x1.201.6 to 5.5-40 to +85+/- 5-30 to +70+/- 13
RX-8803LCX1B0001420004003.60x2.80x1.201.6 to 5.5-40 to +85+5 +/- 5@+25+/- 13
RX-8803SAX1B00015100010010.10x7.40x3.301.6 to 5.5-40 to +85+/- 5-40 to +85+/- 13
RX-8803SAX1B00015100020010.10x7.40x3.301.6 to 5.5-40 to +85+/- 3.4-40 to +85+/- 9
RX-8803SAX1B00015100030010.10x7.40x3.301.6 to 5.5-40 to +85+/- 5-30 to +70+/- 13
RX-8803SAX1B00015100040010.10x7.40x3.301.6 to 5.5-40 to +85+5 +/- 5@+25+/- 13
RX-8035SAX1B00017200010010.10x7.40x3.302.4 to 5.5-40 to +85+5 +/- 23@+25+/- 60
RX-8035SAX1B00017200020010.10x7.40x3.302.4 to 5.5-40 to +85+/- 5@+25+/- 13
RX-8035SAX1B00017200030010.10x7.40x3.302.4 to 5.5-40 to +85+5 +/- 5@+25+/- 13
RX-4035SAX1B00019200010010.10x7.40x3.302.4 to 5.5-40 to +85+5 +/- 23@+25+/- 60
RX-4035SAX1B00019200020010.10x7.40x3.302.4 to 5.5-40 to +85+/- 5@+25+/- 13
RX-4035SAX1B00019200030010.10x7.40x3.302.4 to 5.5-40 to +85+5 +/- 5@+25+/- 13
RX-4035LCX1B0002020002003.60x2.80x1.202.4 to 5.5-40 to +85+/- 5@+25+/- 13
RX6110SAX1B00023200010010.10x7.40x3.301.6 to 5.5-40 to +85+5 +/- 23@+25+/- 60
RX8010SJX1B0002420001007.00x6.00x2.651.6 to 5.5-40 to +85+5 +/- 23@+25+/- 60
RX-8025SAQ4180255200010010.10x7.40x3.301.7 to 5.5-40 to +85+5 +/- 5@+25+/- 13
RA4803SAX1B000252A0020010.10x7.40x3.301.6 to 5.5-40 to +85+/- 5-40 to +85+/- 13
RA8803SAX1B000262A0020010.10x7.40x3.301.6 to 5.5-40 to +85+/- 5-40 to +85+/- 13
RA8803SAX1B000262A0010010.10x7.40x3.301.6 to 5.5-40 to +85+/- 3.4-40 to +85+/- 9

在功耗方面RX8130CE時鐘模塊的表現尤為出色在計時保持狀態下其典型功耗值僅為300nA（3V電源供電）,這一數據遠低于同類產品,極大地延長了備用電池的使用壽命,這一低功耗特性使得RX8130CE時鐘模塊在便攜式設備和可穿戴設備中具有極高的應用價值,除了低功耗RX8130CE時鐘模塊的高精度也是其一大亮點,該模塊內置了溫度補償電路,能夠在寬溫度范圍內自動校正由溫度變化引起的頻率偏差,從而保持穩定而精確的計時性能,據測試愛普生晶振公司這款RX8130CE時鐘模塊在3.0V電壓供電,+25°C環境溫度下的頻率穩定度典型值為（5±23）ppm,相當于每月±1分鐘的偏差,這一高精度特性使得RX8130CE在醫療,通信等對時間精度要求極高的領域具有廣泛的應用前景。

此外EPSON愛普生晶振RX8130CE時鐘模塊還具備強大的電源管理功能,該模塊支持主備電電源管理,并內置了備電電池充電控制功能,用戶僅需直接與VBAT引腳連接,配置相關寄存器,即可通過僅用一個便宜的EDLC器件,獲得一個穩定高效的備用電源,這一功能不僅簡化了電路設計,降低了成本,還提高了系統的穩定性和可靠性,值得一提的是,RX8130CE還提供了豐富的配置選項,用戶可以通過I2C總線接口對內部寄存器進行靈活配置,以滿足不同的應用場景需求,例如用戶可以設置日歷時鐘配置項,喚醒計時配置項,告警配置項以及低壓監控配置項等,此外RX8130CE還劃分了一塊32bit的RAM寄存器空間供用戶自行分配和存儲,最大程度上滿足了用戶的個性化需求。
