SG2520VGN SG2520EGN SG2520VHN差分晶振讓光模塊信號“穩如磐石”
  • 文章出處：http://m.shangyingkeji.cn/
  • 責任編輯：加科電子
  • 人氣：98
  • 發表時間：2025-11-24

在5G數據中心和云計算的驅動下,400G/800G光模塊已成為高速通信的核心組件而作為光模塊的“心臟”時鐘源其性能直接決定了數據傳輸的穩定性與效率,日本愛普生晶振（EPSON）推出的SG2520VHN系列LVDS差分晶振（型號X1G005941001015）憑借156.25MHz高頻,±20ppm精度,38fs超低相位抖動等特性成為400G光模塊時鐘方案的理想選擇助力光通信設備實現“零誤差”傳輸,SG2520VHN覆蓋25MHz至500MHz頻率范圍,支持156.25MHz晶振（400G光模塊標準頻點）及312.5MHz晶振（800G光模塊備選頻點）總頻偏僅±20ppm這一精度可確保光模塊在長距離傳輸中維持時鐘同步避免數據丟包或誤碼。

料號型號頻率輸出電壓工作溫度精度
X1G005881000515SG2520EGN156.25MHzLV-PECL3.135 to 3.465V-40°C ~ 105°C50PPM
X1G005881000115SG2520EGN156.25MHzLV-PECL3.135 to 3.465V-40°C ~ 85°C50PPM
X1G005881000215SG2520EGN156.25MHzLV-PECL3.135 to 3.465V-40°C ~ 85°C25PPM
X1G005881000315SG2520EGN156.25MHzLV-PECL2.375 to 2.625V-40°C ~ 85°C50PPM
SG2520EGN 156.25MHz CJGPZASG2520EGN156.25MHzLV-PECL3.135 to 3.465V-40°C ~ 85°C50PPM
SG2520EGN 156.25MHz CDGPZASG2520EGN156.25MHzLV-PECL3.135 to 3.465V-40°C ~ 85°C25PPM
SG2520EGN 156.25MHz DJGPZASG2520EGN156.25MHzLV-PECL2.375 to 2.625V-40°C ~ 85°C
X1G005921000115SG2520EHN156.25MHzLV-PECL3.135 to 3.465V-40°C ~ 85°C20PPM
SG2520EHN 156.25MHz CCHPZASG2520EHN156.25MHzLV-PECL3.13 to 3.46V-40°C ~ 85°C20PPM
X1G005901000415SG2520VGN156.25MHzLVDS3.135 to 3.465V-40°C ~ 105°C50PPM
X1G005901000715SG2520VGN156.25MHzLVDS1.71 to 1.89V-40°C ~ 105°C50PPM
X1G005901000815SG2520VGN156.25MHzLVDS2.375 to 2.625V-40°C ~ 105°C50PPM
X1G005901000115SG2520VGN156.25MHzLVDS3.135 to 3.465V-40°C ~ 85°C50PPM
X1G005901000215SG2520VGN156.25MHzLVDS1.71 to 1.89V-40°C ~ 85°C50PPM
X1G005901000315SG2520VGN156.25MHzLVDS2.375 to 2.625V-40°C ~ 85°C50PPM
X1G005901000615SG2520VGN156.25MHzLVDS2.375 to 2.625V-40°C ~ 85°C50PPM
SG2520VGN 156.25MHz CJGPZASG2520VGN156.25MHzLVDS3.135 to 3.465V-40°C ~ 85°C50PPM
SG2520VGN 156.25MHz EJGPZASG2520VGN156.25MHzLVDS1.71 to 1.89V-40°C ~ 85°C50PPM
X1G005901000311SG2520VGN156.25MHzLVDS2.375 to 2.625 V-40°C ~ 85°C50PPM
X1G005901000100SG2520VGN156.25MHzLVDS3.135 to 3.465 V-40°C ~ 85°C50PPM
X1G005901000114SG2520VGN156.25MHzLVDS3.135 to 3.465 V-40°C ~ 85°C50PPM
X1G005901000811SG2520VGN156.25MHzLVDS2.375 to 2.625 V-40°C ~ 105°C50PPM
X1G005901000711SG2520VGN156.25MHzLVDS1.710 to 1.890 V-40°C ~ 105°C50PPM
X1G005901000611SG2520VGN156.25MHzLVDS2.375 to 2.625 V-40°C ~ 85°C50PPM
X1G005901000411SG2520VGN156.25MHzLVDS3.135 to 3.465 V-40°C ~ 105°C50PPM
X1G005901000211SG2520VGN156.25MHzLVDS1.710 to 1.890 V-40°C ~ 85°C50PPM
SG2520VGN 156.250000MHz DJGPZASG2520VGN156.25MHzLVDS2.375 to 2.625 V-40°C ~ 85°C50PPM
X1G005941000315SG2520VHN156.25MHzLVDS1.71 to 1.89V-40°C ~ 105°C20PPM
X1G005941000515SG2520VHN156.25MHzLVDS3.135 to 3.465V-40°C ~ 105°C20PPM
X1G005941000915SG2520VHN156.25MHzLVDS2.375 to 2.625V-40°C ~ 105°C20PPM
SG2520VHN 156.25MHz ECHPZASG2520VHN156.25MHzLVDS1.71 to 1.89V-40°C ~ 105°C20PPM
SG2520VHN 156.25MHz CCHPZASG2520VHN156.25MHzLVDS3.135 to 3.465V-40°C ~ 105°C20PPM
X1G005941000615SG2520VHN155.52MHzLVDS3.135 to 3.465V-40°C ~ 85°C20PPM
X1G005941000115SG2520VHN156.25MHzLVDS3.135 to 3.465V-40°C ~ 85°C20PPM
X1G005941000215SG2520VHN156.25MHzLVDS2.375 to 2.625V-40°C ~ 85°C20PPM
X1G005941000415SG2520VHN156.25MHzLVDS1.71 to 1.89V-40°C ~ 85°C20PPM
X1G005941000715SG2520VHN156.25MHzLVDS1.71 to 1.89V-40°C ~ 85°C20PPM
X1G005941001015SG2520VHN156.25MHzLVDS3.135 to 3.465V-40°C ~ 85°C20PPM
X1G005941001115SG2520VHN156.25MHzLVDS1.71 to 1.89V-40°C ~ 85°C20PPM
X1G005941000815SG2520VHN174.73MHzLVDS2.375 to 2.625V-40°C ~ 85°C20PPM
X1G005941060315SG2520VHN400MHzLVDS2.97 to 3.465V-40°C ~ 85°C20PPM
X1G005941060415SG2520VHN400MHzLVDS2.97 to 3.465V-40°C ~ 85°C20PPM
X1G005941060515SG2520VHN467.529297MHzLVDS1.71 to 1.89V-40°C ~ 85°C20PPM
SG2520VHN 156.25MHz CCGPZASG2520VHN156.25MHzLVDS3.135 to 3.465V-40°C ~ 85°C20PPM
SG2520VHN 156.25MHz DCGPZASG2520VHN156.25MHzLVDS2.375 to 2.625V-40°C ~ 85°C20PPM
SG2520VHN 156.25MHz ECGPZASG2520VHN156.25MHzLVDS1.71 to 1.89V-40°C ~ 85°C20PPM
SG2520VHN 391.770000MHz CCGSZASG2520VHN391.77MHzLVDS3.135 to 3.465V-40°C ~ 85°C20PPM
SG2520VHN 391.770000MHz CCGPZASG2520VHN391.77MHzLVDS3.135 to 3.465V-40°C ~ 85°C20PPM
SG2520VHN 156.250000MHz CCGPZASG2520VHN156.25MHzLVDS3.135 to 3.465V-40°C ~ 85°C20PPM
SG2520VHN 156.250000MHz DCGPZASG2520VHN156.25MHzLVDS2.375 to 2.625V-40°C ~ 85°C20PPM
SG2520VHN 156.250000MHz ECHPZASG2520VHN156.25MHzLVDS1.71 to 1.89V-40°C ~ 85°C20PPM
SG2520VHN 156.250000MHz ECGPZASG2520VHN156.25MHzLVDS1.71 to 1.89V-40°C ~ 85°C20PPM
SG2520VHN 156.250000MHz CCHPZASG2520VHN156.25MHzLVDS3.135 to 3.465V-40°C ~ 85°C20PPM

在156.25MHz工作頻率下,SG2520VHN的相位抖動低至38飛秒,僅為行業平均水平的1/3,低抖動特性顯著提升光模塊的信號完整性減少眼圖閉合使高速信號在長距離傳輸中仍保持清晰誤碼率（BER）降低至10?12以下,振蕩啟動時間僅0.35ns,支持光模塊在極短時間內完成時鐘鎖定滿足數據中心對低延遲的嚴苛需求同時年老化率低于±1ppm/年,確保光模塊在10年生命周期內時鐘精度持續穩定,SG2520VHN采用2.5×2.0×0.74mm超小封裝緊湊型設計體積僅為傳統晶振的1/3可輕松集成于光模塊的狹小空間內為PCB布局留出更多余量?jì)?yōu)化散熱與信號走線,SG2520VHN工作溫度 -40°C至+85°C寬溫工作針對數據中心機柜內高溫環境（如45°C以上持續運行）。

SG2520VHN可在-40°C至+85°C范圍內穩定工作（可選-40°C至+105°C擴展溫域）,避免因溫度波動導致的時鐘偏移或停振,在312.5MHz頻率下工作電流僅28mA配合LVDS差分輸出（支持800-1600mV擺幅）,無需外圍下拉電阻進一步降低系統功耗高擺幅設計可增強信號驅動能力提升光模塊與CPU,DSP等芯片的兼容性,此外EPSON晶振愛普生SG2520VHN晶振以高頻,低抖動,小尺寸,寬溫域四大核心優勢為400G/800G光模塊提供了“零妥協”的時鐘解決方案,助力數據中心,5G基站等基礎設施實現高效可靠的數據傳輸。
